Installing the drive 57
ACH550-01 User's Manual
3. Install the connection box and tighten the cable clamps.
Note: The connection box can be left out in cabinet installations
if the cabinet is grounded. Apply 360° grounding of the cable
shields at the cable entries of the cabinet.
