66 Installing the drive
ACH550-01 User's Manual
The figure below shows changing the direction of motor rotation,
seen from the shaft end of the motor.
Note: The direction of rotation can be changed from the drive,
but we recommend switching the motor cables to associate the
drive forward direction with the clockwise motor rotation.
Note: Now the drive is fully operational for manual operation. If
you wish to use I/O connections, refer to chapter Application
macros and wiring.
