106 Parameters
14.45 RO2 src Selects a drive signal to be connected to relay output RO2.
Brake cmd 03.16 Brake command (see page 71). 1073742608
Ready Bit 0 of 06.01 Status word1 (see page 73). 1073743361
Enabled Bit 1 of 06.01 Status word1 (see page 73). 1073808897
Started Bit 2 of 06.01 Status word1 (see page 73). 1073874433
Running Bit 3 of 06.01 Status word1 (see page 73). 1073939969
Alarm Bit 7 of 06.01 Status word1 (see page 73). 1074202113
Ext2 active Bit 8 of 06.01 Status word1 (see page 73). 1074267649
Fault Bit 10 of 06.01 Status word1 (see page 73). 1074398721
Fault(-1) Bit 12 of 06.01 Status word1 (see page 73). 1074529793
Ready relay Bit 2 of 06.02 Status word2 (see page 74). 1073874434
RunningRelay Bit 3 of 06.02 Status word2 (see page 74). 1073939970
Ref running Bit 4 of 06.02 Status word2 (see page 74). 1074005506
Charge ready Bit 9 of 06.02 Status word2 (see page 74). 1074333186
Neg speed Bit 0 of 06.03 Speed ctrl stat (see page 75). 1073743363
Zero speed Bit 1 of 06.03
Speed ctrl stat (see page 75). 1073808899
Above limit Bit 2 of 06.03 Speed ctrl stat (see page 75). 1073874435
At setpoint Bit 3 of 06.03 Speed ctrl stat (see page 75). 1073939971
Supervision1 Bit 0 of 06.13 Superv status (see page 76). 1073743373
Supervision2 Bit 1 of 06.13 Superv status (see page 76). 1073808909
Supervision3 Bit 2 of 06.13 Superv status (see page 76). 1073874445
Const Bit pointer setting (see Terms and abbreviations on page 63). -
Pointer
14.48 RO3 src Selects a drive signal to be connected to relay output RO3.
Brake cmd 03.16 Brake command (see page 71). 1073742608
Ready Bit 0 of 06.01 Status word1 (see page 73). 1073743361
Enabled Bit 1 of 06.01 Status word1 (see page 73). 1073808897
Started Bit 2 of 06.01 Status word1 (see page 73). 1073874433
Running Bit 3 of 06.01 Status word1 (see page 73). 1073939969
Alarm Bit 7 of 06.01 Status word1 (see page 73). 1074202113
Ext2 active Bit 8 of 06.01 Status word1 (see page 73). 1074267649
Fault Bit 10 of 06.01 Status word1 (see page
73). 1074398721
Fault(-1) Bit 12 of 06.01 Status word1 (see page 73). 1074529793
Ready relay Bit 2 of 06.02 Status word2 (see page 74). 1073874434
RunningRelay Bit 3 of 06.02 Status word2 (see page 74). 1073939970
Ref running Bit 4 of 06.02 Status word2 (see page 74). 1074005506
Charge ready Bit 9 of 06.02 Status word2 (see page 74). 1074333186
Neg speed Bit 0 of 06.03 Speed ctrl stat (see page 75). 1073743363
Zero speed Bit 1 of 06.03 Speed ctrl stat (see page 75). 1073808899
Above limit Bit 2 of 06.03 Speed ctrl stat (see page 75). 1073874435
At setpoint Bit 3 of 06.03 Speed ctrl stat (see page 75). 1073939971
No. Name/Value Description FbEq
