ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-10
Table 8-18. Advant Fieldbus 100 for coaxial cable
Description Consists of Article No.
Bus controller for Advant Field-
bus 100 for one single bus and
single bus cable
CI522A
TC625
TK803
3BSE018448R1
Bus controller for Advant Field-
bus 100 for one single bus and
redundant bus cables
CI522A
2xTC625
2xTK803
3BSE018449R1
Bus controller for Advant Field-
bus 100 for one redundant bus
2xCI522A
4xTC625
4xTK803
3BSE018450R1
Advant Fieldbus 100 connector
kit
Drop cable TK516 length = 40 cm
(15,7”). For connection of one
TC513, TC625 or TC630 to a
coaxial bus line. Note: BNC con-
nectors fit RG11 cable
TK516
2 BNC connectors
BNC T-connector
2 red +2 blue marking rings
3BSE006251R1
Advant Fieldbus 100 termina-
tor kit
1x75Ω BNC terminator
plug 1x ditto w. ground lead
3BSE006244R1
Table 8-19. Advant Fieldbus 100 for twisted pair cable
Description Consists of Article No.
Bus controller for Advant Fieldbus 100
for one single bus and single bus cable
CI522A
TC512V1
TK803
3BSE018451R1
Bus controller for Advant Fieldbus 100
for one single bus and cable redundancy
CI522A
2xTC512V1
2xTK803
3BSE018452R1
Bus controller for Advant Fieldbus 100
for one redundant bus
2xCI522A
2xTC512V1
4xTK803
3BSE018453R1
Cable adaptor, for connection of one
TC512 or TC513 to 150 ohm twisted pair
cable
TC501V150
TC505
3BSE009616R1
