ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-11
Table 8-20. Modems for Advant Fieldbus 100
Description Consists of Article No.
Conversion modem from coaxial to twisted
pair or from twisted pair to coaxial cable
TC513V1 3BSE018405R1
Conversion modem from twisted pair to
optical or from optical to twisted pair cable
TC514V2 3BSE013281R1
Repeater modem from twisted pair to
twisted pair cable
TC515V2 3BSE013284R1
Conversion modem from coaxial to optical
or from optical to coaxial cable
TC630 3BSE002253R1
Cable adaptor, for connection of one
TC512, TC513 or TC516 to 150 ohm twisted
pair cable
TC501V150
TC505
3BSE009616R1
Advant Fieldbus 100 connector kit
Drop cable TK516 length = 40 cm (15,7”).
For connection of one TC513, TC625 or
TC630 to a coaxial bus line.
Note! BNC connectors fit RG11 cable
TK516
2 BNC connectors
BNC T-connector
2 red +2 blue
marking rings
3BSE006251R1
Table 8-21. MasterFieldbus
Description Consists of Article No.
Bus controller for MasterFieldbus, for
one bus, single or redundant bus cable
CI570
TC570
TK570
3BSE003565R1
Modem for MasterFieldbus, coaxial cable DSTC 452 5751017-A
Optical modem for MasterFieldbus
2 Mbit/s
DSTC 454 5751017-F
Optical modem for MasterFieldbus
375 kbit/s
DSTC 454L 5751017-R
