ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-16
Table 8-30. Power Supply in RM500V1 Cabinet, 230V a.c. Mains
Description Consists of Article No.
Single a.c. mains supply (SA168K01)
for controller subrack and I/O subrack 1
Input: 230 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA168
SX554
SX540
TK402V014
3BSE003574R1
Red. a.c. mains supply (SA168K03)
for controller subrack and I/O subrack 1
Input: 230 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
2xSA168
2xSX554
2xSX540
2xTK402V014
TK451
3BSE003580R1
a.c. mains supply (SA162K10)
for I/O subrack 2 Input: 230 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA162
SX554
TK402V051
3BSE008783R1
a.c. mains supply (SA168K13) for I/O subrack
2 and 3. Input: 230 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA168
SX554
TK402V051
3BSE008787R1
a.c. mains supply (SA162K11) for I/O
subrack 4. Input: 230 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA162
SX554
TK402V060
3BSE008784R1
Single a.c. mains supply (SA168K14) for I/O
subrack 4 and 5. Input: 230 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA168
SX554
TK402V060
3BSE008788R1
Table 8-31. Power Supply in RM500V1 Cabinet, 24/48V d.c. Mains
Description Consists of Article
Single d.c. mains supply for Controller subrack
and I/O subrack 1. Input: 18.5-30V d.c.
Output: 24V, 20 A, d.c., regulated (<1%)
SD150
SX554
SX555
3BSE004446R1
Red. d.c. mains supply
for Controller subrack and I/O subrack 1.
Input: 18.5-30 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
2xSD150
2xSX554
2xSX555
TK451
3BSE004448R1
Single d.c. mains supply
for controller subrack and I/O subrack 1.
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
SX550
TK582V014
3BSE003585R1
