ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-17
Red. d.c. mains supply
for controller subrack and I/O subrack 1
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
2xSD150
2xSX554
2xSX550
2xTK582V014
TK451
3BSE003587R1
d.c. mains supply for I/O subrack 2 and 3
or 4 and 5. Input:18.5-30V d.c.
Output: 24V, 20A, d.c., regulated (<1%)
SD150
SX554
3BSE004447R1
d.c. mains supply for I/O subrack 2 and 3.
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
TK582V051
3BSE008789R1
d.c. mains supply for I/O subrack 4 and 5.
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
TK582V060
3BSE008839R1
Table 8-32. Power Supply in RM500V1 Cabinet, 24V d.c. Mains (without d.c./d.c. converter)
Description Consists of Article No.
Single d.c. mains supply without d.c./d.c.
conversion (DSSB170K04)
for controller subrack and I/O subrack 1
Energy reservoir
Capacity: 3 ms at 25 A d.c.
DSSB 170
SX555
SX557
3BSE003589R1
Single d.c. mains supply without d.c./d.c.
conversion (DSSB170K05)
for I/O subrack 2 and 3 or 4 and 5.
Energy reservoir
Capacity: 3 ms at 25 A d.c.
DSSB 170
SX557
3BSE003590R1
Table 8-33. Power Supply in RM500V2 Cabinet, 120V a.c. Mains
Description Consists of Article No.
Single a.c. mains supply (SA167K05)
for controller subrack and I/O subrack 1
Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA167
SX554
SX540
TK402V035
3BSE004407R1
Red. a.c. mains supply (SA167K07)
for Controller subrack and I/O subrack 1
Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
2xSA167
2xSX554
2xSX540
2xTK402V035
TK451
3BSE004413R1
Table 8-31. Power Supply in RM500V1 Cabinet, 24/48V d.c. Mains (Continued)
Description Consists of Article

ABB Advant Controller 450 Specifications

General

Brand	ABB
Model	Advant Controller 450
Category	Controller
Language	English
