Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-19
a.c. mains supply (SA162K11)
for I/O subrack 4
Input: 230 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA162
SX554
TK402V060
3BSE008784R1
a.c. mains supply (SA168K14)
for I/O subrack 4 and 5
Input: 230 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA168
SX554
TK402V060
3BSE008788R1
Table 8-35. Power Supply in RM500V2 Cabinet, 24/48V d.c. Mains
Description Consists of Article No.
Single d.c. mains supply
for controller subrack and I/O subrack 1
Input: 18.5-30 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
SX555
3BSE004440R1
Red. d.c. mains supply
for controller subrack and I/O subrack 1
Input: 18.5-30 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
2xSD150
2xSX554
2xSX555
TK451
3BSE004424R1
Single d.c. mains supply
for controller subrack and I/O subrack 1
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
SX550
TK582V043
3BSE004419R1
Red. d.c. mains supply
for controller subrack and I/O subrack 1
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
2xSD150
2xSX554
2xSX550
2xTK582V043
TK451
3BSE004421R1
d.c. mains supply
for I/O subrack 2 and 3 or 4 and 5
Input: 18.5-30 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
3BSE004447R1
