ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-20
d.c. mains supply
for I/O subrack 2 and 3
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
TK582V051
3BSE008789R1
d.c. mains supply
for I/O subrack 4 and 5
Input: 30-60 V d.c.
Output: 24 V, 20 A, d.c., regulated (<1%)
SD150
SX554
TK582V060
3BSE008839R1
Table 8-36. Power Supply in RM500V2 Cabinet, 24V d.c. Mains
(without d.c./d.c. converter)
Description Consists of Article No.
Single d.c. mains supply without d.c./d.c.
conversion (DSSB170K06)
for controller subrack and I/O subrack 1.
Energy reservoir
Capacity: 3 ms at 25 A d.c.
DSSB 170
SX554
SX557
3BSE004423R1
Single d.c. mains supply without d.c./d.c.
conversion (DSSB170K05)
for I/O subrack 2 and 3 or 4 and 5.
Energy reservoir
Capacity: 3 ms at 25 A d.c.
DSSB 170
SX557
3BSE003590R1
Table 8-37. Extra Power Supply in RM500 Cabinet for Field Equipment
Description Consists of Article No.
Single a.c power supply
Input: 120 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA161
SX554
TK402V027
3BSE003591R1
Single a.c power supply
Input: 120 V a.c., 50/60 Hz
Output: 48 V, 5 A, d.c., unregulated
SA171
SX554
TK402V027
3BSE003593R1
Single a.c power supply
Input: 230 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA162
SX554
TK402V027
3BSE003592R1
Single a.c power supply
Input: 230 V a.c., 50/60 Hz
Output: 48 V, 5 A, d.c., unregulated
SA172
SX554
TK402V027
3BSE003594R1
Table 8-35. Power Supply in RM500V2 Cabinet, 24/48V d.c. Mains (Continued)
Description Consists of Article No.
