23
E 0000
F 0000 G 0000
h 0000
Display
0 None
1 0.1%
2 0.2%
3 0.5%
4 1.0%
5 2.0%
6 5.0%
U Custom
H – Alarm Hysteresis
G – Alarm 3 Type
Display
0 None
1 High Process
2 Low Process
3 High Latch
4 Low Latch
E – Alarm 1 Type
Display
0 None
1 High Process
2 Low Process
3 High Latch
4 Low Latch
F – Alarm 2 Type
Display
0 None
1 High Process
2 Low Process
3 High Latch
4 Low Latch
Value in % of
engineering range
Value in engineering units
4 CONFIGURATION MODE…
Note. When custom alarm
hysteresis is selected, the alarm
hysteresis values are set
individually in the Set Up Level –
See section 3.2.
Fig. 4.5 Alarm Setup
