ABB COMMANDER 150 - Operator Mode; Operating Page - Standard (Level 1); Operating Page - Totalizer (Level 1); Operating Page - Maths Functions (Level 1)

5
Alarm 1
COMMANDER 150
Alarm 2
Alarm 3
Alarm LEDs
A1
A2
A3
1 DISPLAYS AND FUNCTION KEYS…
1.3 LED Alarms and Indicators
LED Status
All Flashing
• Indicator is in the configuration mode – see Section 4.2.
A1, A2 and A3
• Flashes when Alarm is active (off when inactive).
• Lit constantly when Alarm 1 is an active latched alarm which has
been acknowledged
Fig. 1.3 LED Alarms and Indicators
