ABB COMMANDER 150 - 1 Displays and Function Keys; Introduction

3
888888
A1
A2
A3
Alarm LEDs
(secret-til-lit)
Display
Function Keys
Parameter Advance
Raise
Lower
Multi-function Key
1 DISPLAYS AND FUNCTION KEYS
Information.
The fold-out page inside on the back cover of this manual
shows all the frames in the programming levels. Space is
provided on the page for writing the programmed setting or
selection for each frame.
1.1 Introduction – Fig. 1.1
The COMMANDER 150 front panel display, function keys and LED indicators are
shown in Fig. 1.1.
Fig. 1.1 Front Panel Display, Function Keys and Indicators
