ABB COMMANDER 150 - Electrical Connections; Relays, Arc Suppression, Inputs and Outputs; Relay Contact Ratings; Arc Suppression

35
5 INSTALLATION…
EC Directive 89/336/EEC
In order to meet the requirements of
the EC Directive 89/336/EEC for
EMC regulations, this product must
not be used in a non-industrial
environment.
5.3 Electrical Connections –
Fig. 5.5 (overleaf)
Warning. Before making
any connections, ensure that the
power supply, any powered control
circuits and high common mode
voltages are switched off.
Note. If it is not possible to
avoid strong electrical and magnetic
fields, screened cables within
earthed metal conduit must be used.
5.4 Relays, Arc Suppression,
Inputs and Outputs
5.4.1 Relay Contact Ratings
Relay contacts are rated at:
115/230V AC at 5A (non-inductive)
250V DC 25W max.
5.4.2 Arc Suppression
Arc suppression components are fitted
to relays 2 and 3 only. If relay 1 is
required to switch inductive loads, fit
the arc suppression components
supplied.
5.4.3 Logic Output
18V DC at 20mA
Min load 900Ω
Isolated from Analog Input
(not isolated from Retransmission
O/P).
Dielectric strength: 500V d.c. for 1
minute.
5.4.4 Retransmission
Analog Output
Max. load 15V (750Ω at 20mA)
Isolated from Analog Input (not
isolated from Logic O/P).
Dielectric strength: 500V d.c. for 1
minute.
5.4.5 Digital Input
Type: Volt-free
Minimum Pulse: 250 ms
