ABB COMMANDER 150 - Mounting

33
3.62
Dimensions in inches (mm)
4.68 (119)
1.57 (40 ) 3.11 (79)
1.76
(44.6)
0.11 (2.7)
0.28 (7.1)
3.78 (96)
1.89
Panel
cut-out
+ 0.03
– 0
(92 )
+ 0.8
– 0
(45 )
+ 0.6
– 0
1.77
+ 0.02
– 0
≥0.55
(14)
≥ 0.55 (14)
5 INSTALLATION…
Fig. 5.3 Overall Dimensions
5.2 Mounting – Figs. 5.3 and 5.4
The instrument is designed for panel mounting (see Fig. 5.4). Overall dimensions are
shown in Fig. 5.3.
