J 0000

K 0000

L 0000

n 0000

Display Max/Min Values Average Value Preset/Predetermined

Displayed Displayed Values Displayed

0 No No No

1 Yes No No

2 Yes Yes No

3 No Yes Yes

4 No No Yes

5 Yes No Yes

6 Yes Yes Yes

L – Operator Level Frame Enable

Display Totalizer Stop/Go Totalizer Reset Max./Min./Average

0 No No No

1 Yes No No

2 No Yes No

3 Yes No Yes

4 No Yes Yes

5 Yes Yes Yes

N – Operator Level Math Function & Totaliser Control Enable

This frame determines which frames appear in the operating page (level 1)

This frame determines which functions the operator can control

J – Totalizer Setup

Display

0 Off

1 Count Up, Wrap Off

2 Count Up, Wrap On

3 Count Down, Wrap Off

4 Count Down, Wrap On

K – Totalizer Display

Decimal Places

Display

0 xxxxxx

1 xxxxx.x

2 xxxx.xx

3 xxx.xxx

4 xx.xxxx

5 x.xxxxx

4 CONFIGURATION MODE…

Fig. 4.6 Totalizer Setup and Operator Functions
