27
P 0000 r 0000
S 0000 t 0000
Display Baud Rate, 2/4 Wire
0 Off
1 2400, 2 Wire
2 2400, 4 Wire
3 9600, 2 Wire
4 9600, 4 Wire
S – Serial Communication
Configuration
Display
0 None
1 Odd
2 Even
T – Serial Communication
Parity
Display
0 None
1 Totalizer Reset
2 Totalizer Stop/Go
3 Average, Max/Min Reset
4 Front Panel Lockout
5 Alarm Acknowledge
P – Digital Input Function
Display
0 0 seconds
1 1 second
2 2 seconds
5 5 seconds
A 10 seconds
b 20 seconds
C 40 seconds
d 60 seconds
R – Analog Input Filter
4 CONFIGURATION MODE…
Fig. 4.8 Digital Function and Serial Communications Configuration
Note. Settings for options P, S and T are only available if the
appropriate option board is fitted.
