EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 49
Key functions in measuring mode
Switch over the display of each individual measured value; in addi-
tion to the digital display, an analog bar with information on the
range limits is shown in this display.
Reduce or increase the contrast of the display.
When a status message is active, press key
first.
OK Switch to menu mode (see page 50).
If a status message is active
: press the key to display the
message list (see page 132).
Number of decimal places
When the screen displays the measured value in physical units (e.g. ppm) the
number of places after the decimal point depends on the size of the set
measuring range:
Span Places after the decimal point
≤ 0.05 5
≤ 0.5 4
≤ 5 3
≤ 50 2
≤ 500 1
> 500 0
For the display of the measured value as a percentage of the whole measur-
ing range (%Span) two places are always shown after the decimal point.
When setting the parameters, the number of decimal places is the same as
in the display in measuring mode.
