9-2 Control Modes MN448
9902 Digital input 1 Digital Input 2 Digital Input 3 (An in 2) Digital input 4 (An in 1) Comments
9
Open: Fwd. Stop
Closed: Fwd. Run
Open: Reverse stop
Closed: Reverse run
Preset speed select 0 Preset speed select 1
Closing digital inputs 1 and
2 together carries out a
fast stop
10
Normally Open
(NO)
Momentary close
to run
Normally Closed (NC)
Momentary open to stop
Open: Analog input 1
Closed: Preset speed 1
Analog input 1
11
Normally Open
(NO)
Momentary close
to Fwd
Normally Closed (NC)
Momentary open to stop
Normally Open (NO)
Momentary close to Rev
Analog input 1
Closing digital inputs 1 and
3 together carries out a
fast stop
12
Open: Stop
(disable)
Closed: Run
(enable)
Close to Run
Open activates fast stop
Open: Analog input 1
Closed: Preset speed 1
Analog input 1
13
Normally Open
(NO)
Momentary close
to Fwd
Normally Closed (NC)
Momentary open to stop
Normally Open (NO)
Momentary close to Rev
Open: Keypad Speed Ref
Closed: Preset speed 1
Closing digital inputs 1 and
3 together carries out a
fast stop
14
1
Open: Stop
(disable)
Closed: Run
(enable)
Preset speed select 0
External trip/thermistor input:
Open: Trip, Closed: Run
Preset speed select 1
Preset speed 1 .. 4
selected as dened in this
table
Note:
1. 1. When PTC motor thermistor is used, 1304 must set to "PTC-th" mode. Otherwise digital input 3 will be used as external trip input (digital
level sensitive). When 1304 is set to "PTC-th", drive will display code "F-Ptc" if thermistor value is larger than 2.5kohm. The trip can only be
reset if the thermistor value drops below 1.9kohm. Thermistor must be connected between terminal 1 (24V DC) and terminal 4 (2nd analog
input). If 1304 is set t other value, the input will be used as external trip trigger input and drive will display code "E-trp" instead if the input is
open.
"E-trp" only happens when drive is enabled (running), however thermistor trip can happen at any time.
Preset Speed selection table for 9902 = 2, 8, 9 or 14:
Preset Speed Select 0 Preset Speed Select 1 Preset Speed
Open Open Preset Speed 1
Closed Open Preset Speed 2
Open Closed Preset Speed 3
Closed Closed Preset Speed 4
