Parameter Denitions 10-3MN448
Parameters in the Short parameter mode
No.
Name/Value e
Description Default
20 LIMITS Maximum frequency
2008 MAXIMUM FREQUENCY /
SPEED LIMIT
Maximum output frequency or motor speed limit – Hz or rpm.
If parameter 9908 MOTOR RATED SPEED > 0, the value entered /
displayed is in RPM
133 Hz
2007…133.0 Hz Maximum frequency
21 STOPPING MODE /
POWER LOSS RESPONSE
Stop mode of the motor
2102 STOP MODE Selects the motor stop function
Setting On Disable On Mains loss
0 Ramp to Stop Ride Through
(Recover energy from load to
maintain operation)
1 Coast Coast
2 Ramp to Stop Fast Ramp to Stop
3 Ramp to Stop
with AC ux braking
Fast Ramp to Stop
Note: Ramp to Stop will follow 2203 DECEL RAMP TIME Fast Ramp to
Stop uses 2206 2nd DECEL RAMP TIME or will coast to a stop
if 2206 = 0
0
22 ACCEL/DECEL Acceleration and deceleration times
2202
ACCELERATION
RAMP TIME
Acceleration ramp time from 0 to base speed (Parameter 9907 MOTOR
RATED FREQUENCY) in seconds.
30.0 s
0.00…600.0 s
Time
2203
DECELERATION
RAMP TIME
Deceleration ramp time from base speed (Parameter 9907 MOTOR
RATED FREQUENCY) to standstill in seconds. When set to zero,
fastest possible ramp time without trip is activated.
30.0 s
0.00…600.0 s
Time
