Modbus-RTU Example Connection A-5MN448
Register Parameter Description Format Min Max Data format / scaling
131 1103 Control mode
U16 0 6
0: Terminal Control
1: Keypad forward only
2: Keypad forward and
reverse
3: Modbus control mode
4: Modbus control with ramp
control
5: PID control
6: PID control with analog
speed sum
7: CAN Open
132 1202 Preset Speed 1 U16 -2008 2008 Internal value (3000 = 50.0Hz)
133 1203 Preset Speed 2 U16 -2008 2008 Internal value (3000 = 50.0Hz)
134 1204 Preset Speed 3 U16 -2008 2008 Internal value (3000 = 50.0Hz)
135 1205 Preset Speed 4 U16 -2008 2008 Internal value (3000 = 50.0Hz)
136 1300
Analog input
format
U16 0 7
0: 0…10V
1: b 0…10V
2: 0…20mA
3: t 4…20mA
4: r4…20mA
5: t 20…4mA
6: r 20…4mA
7: 10…0V
137 1301 Analog iput offset U16 -5000 5000 1dp,e.g. 300=30.0%
138 1302 Analog Input /
Slave Scaling
U16 0 20000 1000 = 100.0%
139 1304 Analog Input 2
Format
U16 0 6
0: 0…10V
1: b 0…10V
2: 0…20mA
3: t 4…20mA
4: r4…20mA
5: t 20…4mA
6: Ptc-th
140 1401 Relay Output
Function
U16 0 9 See user guide for function
details
141 1501 Analog Output
Function
U16 0
10 See user guide for function
details
142 1602 Parameter lock U16 0 1
0: Unlocked
1: Locked
143 1603 Access code
denition
U16 0 9999
