ABB FENA-11 User Manual

EtherNet/IP – Communication protocol 209
 Transparent 32 with one assembly
The Transparent 32 with one assembly, defined by ABB, provides
unaltered 32-bit access to the configured drive profile.
The format of the output assembly is:
20 DATA IN 8 Value (Low Byte)
21 DATA IN 8 Value (High Byte)
22 DATA IN 9 Value (Low Byte)
23 DATA IN 9 Value (High Byte)
24 DATA IN 10 Value (Low Byte)
25 DATA IN 10 Value (High Byte)
Instance 21 (Transparent 32 profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Control Word (Low Byte)
1 Drive Profile 32-bit Control Word
2 Drive Profile 32-bit Control Word
3 Drive Profile 32-bit Control Word (High Byte)
4 Drive Profile 32-bit Reference 1 Word (Low Byte)
5 Drive Profile 32-bit Reference 1 Word
6 Drive Profile 32-bit Reference 1 Word
7 Drive Profile 32-bit Reference 1 Word (High Byte)
Instance 162 (Transparent 16 profile)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ABB FENA-11 Specifications

General

Product Type	Fieldbus Adapter
Series	FENA
Supply voltage	24 V DC
Power consumption	2.5 W
Degree of protection	IP20
Connector Type	RJ45
Flammability Rating	UL 94 V-0
Type	Adapter
Operating Temperature	-25 to +70 °C
Fieldbus protocol	EtherNet/IP
