Inspecting mechanical stops
Use this procedure to inspect mechanical stops on axes 1 and 3.
InformationAction
DANGER
Turn off all:
electric power supply
hydraulic pressure supply
air pressure supply
to the robot, before entering the robot
working area.
1
See figures in Location of mechanical
stops on page 92.
Inspect the mechanical stops.2
Replace if the mechanical stop is:
bent
loose
damaged.
Note
The expected life of gearboxes can be re-
duced as a result of collisions with the
mechanical stop.
3
94 Product manual - IRB 1010
3HAC081964-001 Revision: B
© Copyright 2022 ABB. All rights reserved.
4 Maintenance
4.4.4 Inspecting mechanical stops
Continued
