ABB IRB 640 - Cabling; Cooling Device Axis 1; Position Switches, Axes 1 and 2

Spare Parts
Product Manual IRB 640 15
1.10 Cooling device axis 1
Itm Qty Name Art. no. Rem
1 Cooling axis 1 3HAC 2306-1
1 1 Radial fan 3HAA 0001-UL
2 4 Screw 9ADA 618-56 M6x16 8.8
3 1 Gasket 3HAA 1001-607
4 1 Bracket 3HAB 5882-1
5 2 Gasket 3HAB 6968-1
6 1 Flange 3HAA 1001-605
7 4 Nut 9ADA 267-6 M6 8
8 1 Cover 3HAC 2341-1
9 1 Screw 9ADA 618-61 M6x40 8.8
10 1 Holder 3HAC 2342-1
11 1 Cover 3HAA 0001-VH
12 1 Fan cabling 3HAA 0001-ACE
13 1 Cable gland 3HAB 6509-7 Pr 18.6
16 4 Air filter 3HAA 1001-612
17 1 Sealing plug 2522 253-2 Pr 18.6
1.11 Cabling
21 1 Base cabling 3HAC 3766-1 See section 1.2
CP/CS
21 1 Base cabling 3HAC 3880-1 See section 1.2
CP/CS, CAN
47 1 Axis 2 cabling 3HAC 0703-1 See section 1.2
48 1 Axis 3 cabling 3HAB 8737-1 See section 1.2
17 1 Cabling upper front 3HAC 3953-1 See section 1.7
CP/CS
17 1 Cabling upper front 3HAC 3954-1 CAN
12 1 Fan cabling 3HAA 0001-ACE See section 1.10
1.12 Position switches, axes 1 and 2
Spare part list for position switches on axes 1 and 2 is supplied if the option is ordered.
