ABB LMT Series User Manual

LMT100 AND LMT200 | MAGNETOSTRICTIVE LEVEL TRANSMITTERS | FF OI/LMT100/200/FF-EN REV. A
37
Menu: Device Setup (continued)
Menu/Parameter Value Range Description
Device Setup/Write Protect
Software WP Unlocked, Locked Sets the ability of the user to edit parameters through
software
Hardware WP Unlocked, Locked Sets the ability of the user to edit parameters through
the mechanical switch on the top of the transmitter
housing
Device Setup/Unit Setup
Level Unit mm, cm, m, in, ft Defines unit of measure for level
Flow Unit Liters, Cubic meters, cubic inches, cubic feet, cubic yards,
gallons, Imperial gallons, bushels, barrels, liquid barrels
Defines unit of measure for flow
Volume Unit Liters/second, liters/minute, liters/hour, gallons/second,
gallons/minute, gallons/hour, gallons/day, imperial
gallons/second, imperial gallons/minute, imperial
gallons/ hour, imperial gallons/day, barrels/ second,
barrels/minutes, barrels/ hour, barrels/day, cubic
meters/second, cubic meters/minute, cubic meters/hour,
cubic meters/day, cubic feet/second, cubic feet/minute,
cubic feet/hour, cubic feet/day
Defines unit of measure for volume
Device Setup/Level Damping Time  Allows signal smoothing of the signal.
Device Setup/Device
Variables/Level
Level Units mm, cm, m, in, ft Defines unit of measure for level output type
Lower Range • Non linearized

• Linearized

Upper Range • Non linearized

• Linearized

Level Offset 
Device Setup/Device
Variables/Interface
Lower Range • Non linearized

• Linearized

