AUTOMATIC CONTROL UNIT, OMD800
AUTOMATIC CONTROL UNIT, OMD800
Parameter Values
Digital Inputs Digital Input 4
Digital Input 5
Digital Input 6
Digital Input 7
Digital Input 8
Digital Input 9
Digital Input 10
Digital Input 11
Digital Outputs Digital Output 6
Digital Output 7
Digital Output 8
Digital Output 9
Digital Output 10
Digital Output 12
Voltage Thresholds Volt Threshold Min LN1, -30 %, -29 %, …, -5 %
Volt Threshold Min LN2, -30 %, -29 %, …, -5 %
Volt Threshold Max LN1, +5 %, +6 %, …, +30 %
Volt Threshold Max LN2, +5 %, +6 %, …, +30 %
Voltage Hysteresis Volt Hysteresis Min LN1, -29 %, -28 %, …, -4 %
Volt Hysteresis Min LN2, -29 %, -28 %, …, -4 %
Volt Hysteresis Max LN1, +4 %, +5 %, …, +29 %
Volt Hysteresis Max LN2, +4 %, +5 %, …, +29 %
Frequency Thresholds Freq Threshold Min LN1, -10 %, -9 %, …, -1 %
Freq Threshold Min LN2, -10 %, -9 %, …, -1 %
Freq Threshold Max LN1, +1 %, +2 %, …, +10 %
Freq Threshold Max LN2, +1 %, +2 %, …, +10 %
Frequency Hysteresis Freq Hysteresis Min LN1, -9.8 %, -9.6 %, …, -0.8 %
Freq Hysteresis Min LN2, -9.8 %, -9.6 %, …, -0.8 %
Freq Hysteresis Max LN1, +0.8 %, +1.0 %, …, +9.8 %
Freq Hysteresis Max LN2, +0.8 %, +1.0 %, …, +9.8 %
Delay Times Switching, 0…60 s
Delay on Transfer, 0…10 min
Pre-trans I to II, 0...120 s
Dead Band I to II, 0…60 s
Back Switching, 0…90 min
Pre-trans II to I, 0...120 s
Dead Band II to I, 0…60 s
Generator Stop, 0…30 min
Auto Switch to O Off
LN1 to O
LN2 to O
LN1 & LN2 to O
LCD Backlight Timer Always On / 1 sec, …, 59 sec, 1 min, …, 60 min
Modbus Modbus Address
Modbus Baud Rate
Modbus Stop Bits
Modbus Parity
Local / Remote
