PGC5007 Operating Instructions 6 Liquid sample valve repair
34 OI/PGC5007-EN, Rev C
2. Install the Liquid Sample Valve on the analyzer, making sure the insulation and insulation retainer are in the proper
location around the vaporizer.
3. Orient the flange so that the marks made at valve removal are lined up. This should have the sample chamber vertical,
with the air connections at the top of the valve and the connection of the vaporizer chamber at the top.
4. Install the four screws holding the flange to the side of the analyzer and tighten the screws.
5. At the right side of the furnace reconnect the carrier line as follows (reference Figures 5.3 and 5.4):
a. Use the ABB Tee wrench to hold the nut.
b. Connect he 9/16-inch line just outside the furnace tube.
6. Reconnect all tubing on the Liquid Sample Valve.
7. Close the isothermal oven door.
