Table 5: Relay confi guration parameters read
Address Value
Data Value Description
Dec Hex
0032 0x0020
0 Model type CEI 0-16
1 Model type IEC
0033 0x0021
0 Nominal current 0040 A
1 Nominal current 0080 A
2 Nominal current 0250 A
3 Nominal current 1250 A
0034 0x0022 0 Product type REF601
0035 0x0023
0 Earth type - Internal
1 Earth type - External
0036 0x0024 0 - 9999 Software version
0037 0x0025 0 - 9999 Phase trip counter
0038 0x0026 0 - 9999 Earth trip counter
Table 6: Data log to address mapping
Block 1
Address range
Description
Dec
Hex
0000 - 0015 0x0000 - 0x000F Data samples 01 to 04
0016 - 0031 0x0010 - 0x001F Data samples 05 to 08
0032 - 0047 0x0020 - 0x002F Data samples 09 to 12
0048 - 0059 0x0030 - 0x003B Data samples 13 to 15
Block 2
Address range
Description
Dec
Hex
0060 - 0063 0x003C - 0x003F Data samples 01
0064 - 0079 0x0040 - 0x004F Data samples 02 to 05
0080 - 0095 0x0050 - 0x005F Data samples 06 to 09
0096 - 0111 0x0060 - 0x006F Data samples 10 to 13
0112 - 0119 0x0070 - 0x0077 Data samples 14 to 15
