1MDU07205-YN rev. F
REF601 CEI
User’s manual
89
The 2 blocks of data log contains 15 current values in each block with 5 pre-
trip and 10 post trip values. An example to read the above table is as follows:
Address range
Data log mapping Description
Dec Hex
0000 0x0000 Current I1 of 1st sample
Data log of 1st sample
0001 0x0001 Current I2 of 1st sample
0002 0x0002 Current I3 of 1st sample
0003 0x0003 Current I0 of 1st sample
0004 0x0004 Current I1 of 2nd sample
Data log of 2nd sample
0005 0x0005 Current I2 of 2nd sample
0006 0x0006 Current I3 of 2nd sample
0007 0x0007 Current I0 of 2nd sample
0008 0x0008 Current I1 of 3rd sample
Data log of 3rd sample
0009 0x0009 Current I2 of 3rd sample
0010 0x000A Current I3 of 3rd sample
0011 0x000B Current I0 of 3rd sample
0012 0x000C Current I1 of 4th sample
Data log of 4th sample
0013 0x000D Current I2 of 4th sample
0014 0x000E Current I3 of 4th sample
0015 0x000F Current I0 of 4th sample
Serial Communication
