Table 7: Event log to address mapping
Address range
Event log mapping Description
Dec Hex
256 0x0100 Event Word for I1
Event 1
257 0x0101 Event Word for I2
258 0x0102 Event Word for I3
259 0x0103 Event Word for I0
260 0x0104 Port Status
261 0x0105 Event Word for I1
Event 2
262 0x0106 Event Word for I2
263 0x0107 Event Word for I3
264 0x0108 Event Word for I0
265 0x0109 Port Status
266 0x010A Event Word for I1
Event 3
267 0x010B Event Word for I2
268 0x010C Event Word for I3
269 0x010D Event Word for I0
270 0x010E Port Status
271 0x010F Event Word for I1
Event 4
272 0x0110 Event Word for I2
273 0x0111 Event Word for I3
274 0x0112 Event Word for I0
275 0x0113 Port Status
276 0x0114 Event Word for I1
Event 5
277 0x0115 Event Word for I2
278 0x0116 Event Word for I3
279 0x0117 Event Word for I0
280 0x0118 Port Status
