Table 9: Event log - Port status mapping
Bit position Value ( 1=on, 0=off ) Description
0 0 - 1 Input breaker open
1 0 - 1 Input breaker closed
2 0 - 1 Input reset
3 0 - 1 Remote control
4 0 - 1 Unit ready
5 0 - 1 IRF output
6 0 - 1 Phase protection
7 0 - 1 Earth protection
8 0 - 1 Output breaker open
9 0 - 1 Output breaker close
Address range Data range
Data log mapping
Dec Hex Dec Hex
0512 0x0200 0 - 65535 0-0xFFFF Current measurement on I1
0513 0x0201 0 - 65535 0-0xFFFF Current measurement on I2
0514 0x0202 0 - 65535 0-0xFFFF Current measurement on I3
0515 0x0203 0 - 65535 0-0xFFFF Current measurement on Io
Table 10: Current measurement address mapping
CH#
Address
Data log mapping
Dec Hex
01 00 0x00 Breaker open
02 01 0x01 Breaker close
03 02 0x02 Reset protection command
04 03 0x03 Remote trip command
Table 11: Digital output channel to address mapping
