ABB REF601 CEI - Page 93

1MDU07205-YN rev. F
REF601 CEI
User’s manual
93
Address
Data Value Data log mapping
Dec Hex
IEC MODE
0033 0x0021
0 Nominal current 0040A
1 Nominal current 0080A
2 Nominal current 0250A
3 Nominal current 1250A
0035 0x0023
0 Earth type - Internal
1 Earth type - External
CEI MODE
Table 12: Relay confi guration write
Baud Rate response value Description
0 2400 baud
1 4800 baud
2 9600 baud
3 19200 baud
0 38400 baud
Table 13: Baud rate mapping
Parity response value Description
0 None parity
1 Odd parity
2 Even parity
Table 14: Parity mapping
Serial Communication
0033 0x0021
1 Nominal current 0080A
2 Nominal current 0250A
