Function IEC 61850 IEC 60617 REF615R
Residual overvoltage protection, instance 1 ROVPTOV1 Uo> (1) 59G
Residual overvoltage protection, instance 2 ROVPTOV2 Uo> (2) 59N-1
Three-phase undervoltage protection, instance 1 PHPTUV1 3U< (1) 27-1
Three-phase undervoltage protection, instance 2 PHPTUV2 3U< (2) 27-2
Three-phase overvoltage protection, instance 1 PHPTOV1 3U> (1) 59-1
Three-phase overvoltage protection, instance 2 PHPTOV2 3U> (2) 59-2
Negative-sequence overvoltage protection, instance 1 NSPTOV1 U2> (1) 47-1
Negative-sequence overvoltage protection, instance 2 NSPTOV2 U2> (2) 47-2
Frequency protection, instance 1 FRPFRQ1 f>/f<,df/dt (1) 81-1
Frequency protection, instance 2 FRPFRQ2 f>/f<,df/dt (2) 81-2
Voltage per hertz protection, instance 1 OEPVPH1 U/f> (1) 24
Three-phase thermal protection for feeders, cables and distribution
transformers, Instance 1
T1PTTR1 3Ith>F (1)
49F-1
Numerical stabilized low impedance restricted earth-fault protection LREFPNDF1 dIoLo> 87LOZREF
Circuit breaker failure protection, instance 1 CCBRBRF1 3I>/Io>BF (1) 50BF-1
Three-phase inrush detector, instance 1 INRPHAR1 3I2f> (1) INR-1
Master trip, instance 1 TRPPTRC1 Master Trip (1) 86/94-1
Master trip, instance 2 TRPPTRC2 Master Trip (2) 86/94-2
Arc protection, instance 1 ARCSARC1 ARC (1) AFD-1
Arc protection, instance 2 ARCSARC2 ARC (2) AFD-2
Arc protection, instance 3 ARCSARC3 ARC (3) AFD-3
High impedance fault detection PHIZ1 PHIZ1 HIZ
Load shedding and restoration, instance 1 LSHDPFRQ1 UFLS/R (1) 81LSH-1
Load shedding and restoration, instance 2 LSHDPFRQ2 UFLS/R (2) 81LSH-2
Loss of phase, instance 1 PHPTUC1 3I< (1) 37-1
Control
Circuit-breaker control, instance 1 CBXCBR1 I <-> O CB (1) 52-1
Auto-reclosing DARREC1 O -> I 79
Synchronism and energizing check SECRSYN1 SYNC 25
Condition monitoring
Circuit-breaker condition monitoring, instance 1 SSCBR1 CBCM (1) 52CM-1
Current circuit supervision CCRDIF1 MCS 3I CCM
Fuse failure supervision, intance 1 SEQRFUF1 FUSEF (1) 60-1
Cable fault detection RCFD1 RCFD CFD
Measurement
Three-phase current measurement, instance 1 CMMXU1 3I IA, IB, IC
Sequence current measurement, instance 1 CSMSQI1 I1, I2, I0 I1, I2, I0
Table continues on next page
1MRS240044-IB A Section 1
Introduction
REF615R 9
Engineering Manual
