Function IEC 61850 IEC 60617 REF615R
Residual current measurement, instance 1 RESCMMXU1 Io IG
Three-phase voltage measurement, instance 1 VMMXU1 3U VA, VB, VC
Residual voltage measurement, instance 1 RESVMMXU1 Uo VG
Sequence voltage measurement, instance 1 VSMSQI1 U1, U2, U0 V1, V2, V0
Single-phase power and energy measurement, instance 1 SPEMMXU1 SP, SE SP, SE-1
Three-phase power and energy measurement, instance 1 PEMMXU1 P, E P, E-1
Current total demand distortion, instance 1 CMHAI1 PQM3I PQI-1
Voltage total harmonic distortion, instance 1 VMHAI1 PQM3U PQVPH-1
Voltage variation, instance 1 PHQVVR1 PQ 3U<> PQSS-1
Voltage unbalance, instance 1 VSQVUB1 PQMUBU(1) PQVUB-1
Load profile LDPMSTA1 - LoadProf
Frequency measurement, instance 1 FMMXU1 f f
Other
Minimum pulse timer (2 pcs), instance 1 TPGAPC1 TP (1) TP (1)
Minimum pulse timer (2 pcs), instance 2 TPGAPC2 TP (2) TP (2)
Minimum pulse timer (2 pcs), instance 3 TPGAPC3 TP (3) TP (3)
Minimum pulse timer (2 pcs), instance 4 TPGAPC4 TP (4) TP (4)
Minimum pulse timer (2 pcs, second resolution), instance 1 TPSGAPC1 TPS (1) 62CLD-1
Minimum pulse timer (2 pcs, minute resolution), instance 1 TPMGAPC1 TPM (1) 62CLD-2
Pulse timer (8 pcs), instance 1 PTGAPC1 PT (1) PT-1
Pulse timer (8 pcs), instance 2 PTGAPC2 PT (2) PT-2
Time delay off (8 pcs), instance 1 TOFGAPC1 TOF (1) TOF-1
Time delay off (8 pcs), instance 2 TOFGAPC2 TOF (2) TOF-2
Time delay on (8 pcs), instance 1 TONGAPC1 TON (1) TON -1
Time delay on (8 pcs), instance 2 TONGAPC2 TON (2) TON -2
Set reset (8 pcs), instance 1 SRGAPC1 SR (1) SR-1
Set reset (8 pcs), instance 2 SRGAPC2 SR (2) SR-2
Set reset (8 pcs), instance 3 SRGAPC3 SR (3) SR-3
Set reset (8 pcs), instance 4 SRGAPC4 SR (4) SR-4
Move (8 pcs), instance 1 MVGAPC1 MV (1) MV-1
Move (8 pcs), instance 2 MVGAPC2 MV (2) MV-2
Move (8 pcs), instance 3 MVGAPC3 MV (3) MV-3
Move (8 pcs), instance 4 MVGAPC4 MV (4) MV-4
Move (8 pcs), instance 5 MVGAPC5 MV (5) MV-5
Move (8 pcs), instance 6 MVGAPC6 MV (6) MV-6
Move (8 pcs), instance 7 MVGAPC7 MV (7) MV-7
Table continues on next page
Section 1 1MRS240044-IB A
