Function IEC 61850 IEC 60617 REF615R
Move (8 pcs), instance 8 MVGAPC8 MV (8) MV-8
Generic control points, instance 1 SPCGGIO1 SPC(1) CNTRL-1
Generic control points, instance 2 SPCGGIO2 SPC(2) CNTRL-2
Generic control points, instance 3 SPCGGIO3 SPC(3) CNTRL-3
Remote Generic control points, instance 1 SPCRGGIO1 SRCR(1) RCNTRL-1
Local Generic control points, instance 1 SPCLGGIO1 SPCL(1) LCNTRL-1
Programmable buttons(16 buttons), instance 1 FKEYGGIO1 FKEY FKEY
Generic Up-Down Counters, instance 1 UDFCNT1 CTR(1) CTR-1
Generic Up-Down Counters, instance 2 UDFCNT2 CTR(2) CTR-2
Generic Up-Down Counters, instance 3 UDFCNT3 CTR(3) CTR-3
Shift register, instance 1 SHFTGAPC1 SHFT(1) SHFT-1
Shift register, instance 2 SHFTGAPC2 SHFT(2) SHFT-2
Shift register, instance 2 SHFTGAPC3 SHFT(3) SHFT-3
Logging functions
Disturbance recorder RDRE1 - DFR
Fault recorder FLTMSTA1 - FR
Sequence event recorder SER - SER
Fault location DRFLO1 FLO FLO
1MRS240044-IB A Section 1
Introduction
REF615R 11
Engineering Manual
