Setting up a PCM600 project
• The plant structure is built according to the substation structure.
See PCM600 documentation for the recommended size of a
project. Larger projects can be divided into several PCM600 projects.
• In order to add an IED to a project, a suitable ConnPack is needed. IEDs can be
added either while connected, disconnected or through other means such as an IED
template.
• IED objects are uniquely named within the PCM600 project.
Application configuration in the Application Configuration tool
• Protection and control functions can be configured as needed.
• The configuration made in the Application Configuration tool is saved to make the
interfaces and signals available for other engineering tools within PCM600, for
example, for the Parameter Setting tool.
Parameter setting and configuration in the Parameter Setting tool
• Configuration parameters such as CT and VT conversion values of the transformer
module are checked by the tool.
• If needed, the setting values are checked and adjusted with the Parameter Setting
tool.
Single-line diagram configuration in the Graphical Display Editor
• It is possible to create a single-line diagram for the switching devices in the bay.
• Measurements can be included when needed.
• The dynamic elements are linked to the functions created in the Application
Configuration tool; for example, a breaker object is linked to the circuit breaker
control function.
LHMI engineering
• The LED behavior is defined with Parameter Setting.
• The LEDs are configured with Application Configuration.
Communication protocol engineering
Section 2 1MRS240044-IB A
IED engineering process
20 REF615R
Engineering Manual
