Name of OUTx Type Description Value when
activated
Value when
deactivated
OUT14 BOOLEAN Output 14 8192 0
OUT15 BOOLEAN Output 15 16384 0
OUT16 BOOLEAN Output 16 32768 0
The sum of the numbers in column “Value when activated” when all OUTx (1≤x≤16)
are active equals 65535. This is the highest integer that can be converted by the
ITBGAPC function block.
16.12 Pulse integrator TIGAPC
GUID-A01AA9D8-6030-4A16-A671-CC2D8E739D58 v3
16.12.1
Identification
GUID-C565D235-A935-4405-839D-AAF98E6CB85F v3
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Pulse integrator TIGAPC
16.12.2 Application
GUID-8CA0B007-0A59-46E1-9C2E-89A0F0999279 v3
The pulse integrator function TIGAPC is intended for applications where there is a
need for a integration of a pulsed signal. For example, the pulses from the pickup
output of certain functions, like reverse power
, loss of excitation and pole slip. Some
applications may require the integration of the pickup output of those functions to
perform the trip.
16.12.3 Setting guidelines
GUID-FD076D19-B803-4BBB-8320-62CFEEFB677A v2
The pulse integrator function provides settings for time delay to operate and time delay
to reset. The time delay to operate setting is evaluated for activation of the output and
there will be no output until the integration of the input pulses equals this setting. The
output will be deactivated when the input signal is deactivated and the time delay to
reset has elapsed.
1MRK 502 071-UUS A Section 16
Logic
Generator protection REG670 2.2 ANSI and Injection equipment REX060, REX061, REX062 671
Application manual
