This setting is only important if the AnalogDataType setting is selected as
Integer. More information is available under the section Scaling Factors for
ANALOGREPORT channels.
• AnalogXUnitType: Unit type for analog signal X. It refers to the 4-byte
ANUNIT field of the configuration frames 1, 2 or
ganization defined in IEEE
C37.118.2 message format. The options are Single point-on-wave, RMS of
analog input and Peak of analog input.
Section 6 1MRK 504 163-UUS A
Wide area measurement system
134 Transformer protection RET670 2.2 ANSI
Application manual
