ABB REQ650 Commissioning Manual

• Select Main menu/Tests/LED test.
•
Press simultaneously
and .
All the LEDs are tested by turning them on simultaneously. The display shows a set
of patterns so that all the pixels are activated. After the test, the display returns to
normal state.
8.2 Indication messages
8.2.1 Internal faults
When the Ready LED indicates an internal fault by flashing, the message associated with
the fault is found in the internal event list in the LHMI menu Main menu/Diagnostics/
Internal events. The message includes the date, time, description and signal state for the
fault. The internal event list is not updated dynamically. The list is updated by leaving the
Internal events menu and then selecting it again. The current status of the internal fault
signals can also be checked via the LHMI in Main menu/Diagnostics/IED status.
Different actions are taken depending on the severity of the fault. If the fault is found to
be permanent, the IED stays in internal fault mode. The IED continues to perform internal
tests during the fault situation.
When a fault appears, the fault indication message is to be recorded and stated when
requesting support or service.
Table 4: Internal fault indications
Fault indication
Additional information
Internal Fault
Real Time Clock Error
Hardware error with the real time clock.
Internal Fault
Runtime Exec. Error
One or more of the application threads
are not working properly.
Internal Fault
SW Watchdog Error
This signal will be activated when the
terminal has been under too heavy load
for at least 5 minutes.
Internal Fault
Runtime App Error
One or more of the application threads
are not in an expected state.
Internal Fault
File System Error
A file system error has occurred.
Table continues on next page
1MRK 505 293-UUS A Section 8
Troubleshooting
127
Commissioning manual
