ABB REQ650 Commissioning Manual

IEC 61850 or Function
name
ANSI Function description Breaker
REQ650
REQ650 (A01A)
3Ph/1CB/1BB
REQ650 (A11A)
1Ph/1CB/1BB
REQ650 (B11A)
1Ph/1CB/2BB
DPGGIO IEC 61850 generic communication I/O functions
double point
16 16 16 16
SPC8GGIO Single point generic control 8 signals 5 5 5 5
AUTOBITS AutomationBits, command function for DNP3.0 3 3 3 3
I103CMD Function commands for IEC60870-5-103 1 1 1 1
I103IEDCMD IED commands for IEC60870-5-103 1 1 1 1
I103USRCMD Function commands user defined for
IEC60870-5-103
4 4 4 4
I103GENCMD Function commands generic for IEC60870-5-103 50 50 50 50
I103POSCMD IED commands with position and select for
IEC60870-5-103
50 50 50 50
SCILO 3 Logical node for interlocking
SCSWI Switch controller
QCBAY Bay control 1 1 1 1
LOCREM Handling of LR-switch positions 1 1 1 1
LOCREMCTRL LHMI control of Permitted Source To Operate
(PSTO)
1 1 1 1
CBC1 Circuit breaker control for 1CB 1 1 1 1
Secondary system supervision
CCSRDIF 87 Current circuit supervision 0–1 1 1 1
SDDRFUF Fuse failure supervision 0–1 1 1 1
TCSSCBR Breaker close/trip circuit monitoring 3 3 3 3
Logic
SMPPTRC 94 Tripping logic, common 3–phase output 1 1
SPTPTRC 94 Tripping logic, phase segregated output 1 1 1
TMAGGIO Trip matrix logic 12 12 12 12
OR Configurable logic blocks 283 283 283 283
INVERTER Configurable logic blocks 140 140 140 140
PULSETIMER Configurable logic blocks 40 40 40 40
GATE Configurable logic blocks 40 40 40 40
XOR Configurable logic blocks 40 40 40 40
LOOPDELAY Configurable logic blocks 40 40 40 40
TIMERSET Configurable logic blocks 40 40 40 40
Table continues on next page
1MRK 505 293-UUS A Section 2
Available functions
15
Commissioning manual
