4 Assembly and Installation

D184B122U02 S4 11

4.3 Installation Examples

Fig. 2: Mounting Recommendations for Cluster Mounting

min. 62

min. 175

Opening the housing cover

– Loosen the cover screws

– Remove cover or flip open cover with window

Closing the housing cover

– Press the cover with the window on the side with the cover

screws against the gasket and tighten the screws

– Set the small cover on the frame and tighten the screws
