ABB SE41F - Replaceable Parts List Converter Field Mount Housing

9 Maintenance
58 S4 D184B122U02
9.13 Replaceable Parts List Converter Field Mount Housing
Fig. 28: Replaceable Parts Converter Field Mount Housing
No. Description Part No.
1
2
3
4
5
6
7
8
9
10
11
12
Converter U high voltage without HART
Converter U high voltage with HART
Converter U high voltage with PROFIBUS PA
Converter U low voltage with HART
Converter U low voltage with PROFIBUS PA
Connection board Standard
Connection board for PA/FF
Cover large, complete
PVC protection cover
Mach. screw, Phillps, phillister head M 3x5 DIN 7985 SS
Cover, small
Interconnection diagram
Flat cable clamp
Field Mount Housing empty
Cable connector M 20x1.5
Mach. screw, Phillps, phillister head M4x10 steel galv.
Spring washer A 4.0 DIN 137 SS
D674A859U01
D674A859U02
D674A859U03
D674A860U01
D674A860U02
D685A1020U03
D685A1020U02
D641A030U01
D626A005U01
D004F105AU20
D641A029U01
D338D311U01
D174D002U03
D641A033U01
D150A008U15
D004G108AU01
D085D020AU20
X
X
1
2
11,12
5
9
4
5
3
6
10
Anschlussplan / connection diagram / schema de raccordements
7
8
View without cover.
(Backside) Cover large
(Backside) Cover small
