13 Parameter Setting and Option Overview
66 S4 D184B122U02
13 Parameter Setting and Option Overview
1) The maximum count frequency (5 kHz) may not be exceeded.
Meter Location: TAG-No.:
Flowmeter Primary Type: Converter Type:
Order No.: Instrument No.: Order No.: Instrument No.:
Fluid Temp.: Supply Power: V Hz
Liner: Electrodes: Excitation Frequency: Hz
Cs: Cz: System Zero:
Phase: Reference Voltage:
Parameter Setting Range
Prog. Prot. Code: 0–9999 ( 0 = Factory setting)
Language: German, English, French, Finish, Spanish, Italian,
Dutch, Danish, Swedish
Primary: SE2_, SE4_; DS2_; DS4_ (≤DN300/12”); DS21/DS41, 10DS3111A-D (≤DN400/16”),
10DS3111E (≤DN300/12”), 10DI1425 (≤DN400/16”), DS4_ (≥DN350-400/14”-16”),
10DS3111E (≥DN350-400/14”-16”), 10DS3111A-D (≥DN500/20”),DS4_(≥DN500/20”),
10DS3111E (≥DN500/20”), 10D1422, 10DI1425 (≥ DN 500/20”),
Meter Size: DN 1 – 1000 / 1/25” - 40”
Q
max
: 0.05 Cal-fact to Cal-fact
Pulse Factor: 1) pulses/unit (observe dynamic limits)
Pulse Width: 1) ms (observe dynamic limits)
Low Flow Cutoff: 0–10 % of flow range end value
Damping: 0.2–20.0 seconds (= 1τ) Operating Mode: Standard, Piston Pump (0.2–3 sec)
0.07–20.0 seconds (= 1 τ ) Operating Mode: Fast
Density: 0.01 g/cm
3
– 5.0 g/cm
3
Units Q
max
: l/s, l/min, l/g,hl/s, hl/min, hl/h, m
3
/s, m
3
/min, m
3
/h, igps, igpm, igph, mdg, gpm, gph, bbl/
s, bbl/min, bbl/h, bls/day, bls/min, bls/h, kg/s, kg/h, t/s, t/min, t/h, g/s, g/min, g/h, ml/s,
ml/min, ml/h, MI/min, MI/h, MI/day, lb/s, lb/min, lb/h, uton/min, uton/h, uton/day,
kgal/s, kgal/min, kgal/h
Units Totalizer: l, hl, m
3
, igl, mgal, bbl, bls, kg, t, g, ml, MI, lb, uton, kgal
Max. Alarm: %
Min. Alarm: %
Contact Output: F/R Signal, General Alarm, Min-Alarm, Max-Alarm, Max-/Min-Alarm, Empty Pipe
Contact Input Ext. Totalizer Reset, Ext. Zero Return
Current Output: 0/4–20 mA, 0/2–10 mA
I
out
Low Alarm: 2-10 mA: 1.6-2 mA / 4-20 mA: 2-3.5 mA
I
out
High Alarm: 0/4-20 mA: 20-26 mA / 0/2-10 mA: 10-12 mA
Detector e. Pipe: ON/OFF
I
out
at e. Pipe: See I
out
Low Alarm, I
out
High Alarm
Threshold: 0–10000
Adjust e. Pipe:
1st Display Line: Q [%]; Q [Unit]; Q [mA]; Q [m/s]; Q [Bargraph]; Totalizer; Totalizer\→ F; Totalizer\← R;
Tag Number; Blank Line
2nd Display Line: same as above
3rd Display Line: same as above
4th Display Line: same as above
Operating Mode: Standard/Piston Pump/Fast
Flow Indication: Forward/Reverse, Forward
Flow Direction: Standard, Invers
Pulse Output: ❏ Active ❏ Passive
Communication: ❏ HART-Protocol ❏ PROFIBUS PA ❏ No
Detector empty Pipe: ❏ Yes, activated ❏ No (Meter size too small, preamplifier)
Alarm: ❏ Ye s ❏ No
Ext. Input: ❏ Yes Ext. Totalizer Reset ❏ Yes Ext. Zero Return ❏ No
