ABB SE41F - 5.5 Interconnection Diagrams: Flowmeter Primaries DN 1 - 1000 [125 - 40], Converter Field Mount Housing

5 Electrical Interconnections Converter
14 S4 D184B122U02
5.5 Interconnection Diagrams: Flowmeter Primaries DN 1 - 1000 [1/25” - 40”],
Converter Field Mount Housing
5.5.1 Flowmeter Primary Standard DN 10 - 1000 [3/8” - 40”]
Fig. 5: Interconnection Diagram Standard DN 10 to DN 1000 [3/8” to 40”]
2-
L
M3
M13231
51 52
41
N
1+
1)2)3)4)
82
1
2S
2
16
1S
3
42
6)7)
2S
3
1S
16
3
SE
M3
M1
SE
3
81
24 V
+
-
5)
12
2-
L
M3
M13231
51 52
41
N
1+
1)2)3)4)
82
1
2S
2
16
1S
3
42
6)7)
2S
3
1S
16
3
SE
M3
M1
SE
3
81
24 V
+
-
5)
12
Earth
Earth
Converter S4
Wall Mount Housing
Flowmeter Primary
Comment:
We recommend that shielded output cables be used with the shields connected to earth at one end.
1) Supply Power
High voltage:
Low voltage:
Frequency:
AC 85–253 V
Terminals L, N,
AC 20.4 to 26.4 V
DC 20.4 to 31.2 V
Terminals 1+, 2-,
47 Hz ≤ f ≤ 53 Hz; 50 Hz supply power
56 Hz ≤ f ≤ 64 Hz, 60 Hz supply power
2) Magnet Coil Supply: Shielded 2 x 1 mm² CE Typ 227 TEC 74
ABB Part No. D173D147U01
10 m included in shipment, standard
3) – 6) Output Cables See Page 18
7) Shielded Signal Cable: ABB Part No. D173D018U02, 10 m included in shipment.
