3 Flowmeter Primary and Converter Coordination
D184B122U02 S4 9
3 Flowmeter Primary and Converter Coordination
3.1 Metering System Design
A magnetic flowmeter system is comprised of a flowmeter primary and a converter. The flowmeter primary
is installed in the pipeline while the converter for evaluating the flow signals can be mounted locally at the
meter location or in a centralized location.
3.2 Application Areas
The electromagnetic flowmeter provides a precise and economical system for metering the flow liquids, slur-
ries and pastes with an electrical conductivity of at least 20 µS/cm (option 0.5 µS/cm). The measurement
system is especially suited for fast changing processes, two phase fluids, continuous or pulsating flows
(piston pump operation).
3.3 Model Number Coordination
3.4 Operating Instructions
ABB Part No.: D184B121U02 FSM4000 ABB Part No.: D184B122U02
3.5 Condensed Instructions
Assembly and Installation
ABB Part No.: D184B121U11
3.6 Specifications Converter
FSM4000 ABB Part No.: D184S073U02
!
Attention!
You are using a flowmeter system designed for AC magnetic field technology. The flowmeter system con-
sists of a flowmeter primary for installation in the pipeline and a remotely mounted converter. To
assure proper operation only the Model S4 converter should be used. The complete model number is listed
on the type tag.
Flowmeter System using AC Magnetic Field Excitation
Flowmeter Primary Converter
Flowmeter Primary Converter
Stn. stl. housing Series 2000 FSM4000 S4
SE21_/SE21F (Flanged)
Older models Series 2000 MAG-SM S4 compatible
DS21_/DS21F, 10DS2111
Aluminum housing Series 4000 FSM4000 S4
SE41F (Flanged)
Older models Series 3000/4000 MAG-SM S4 compatible
DS41F/DS44F, 10DS3111/2,
10DS3121, 10DI1425, 10D1422
