Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Submenu
Systemdata
Submenu
ENTER Converter
Submenu
This menu is not displayed for PROFIBUS
PA or for excitation frequencies 60 Hz or
70 Hz.
Data 50 Hz
Channel view only
Adjustment value for Channel can be moni-
tored for the excitation frequency setting
(displayed when an older primary 50 Hz has
been selected).
ENTER -123 µs
Zero view only
Adjustment value for Zero can be monitored
for the excitation frequency setting (dis-
played when an older primary 50 Hz has
been selected).
0 %
Span → F view only
Adjustment value for Span Forward can be
monitored for the excitation frequency set-
ting (displayed when an older primary 50 Hz
has been selected).
91 %
Span ← R view only
Adjustment value for Span Reverse can be
monitored for the excitation frequency set-
ting (displayed when an older primary 50 Hz
has been selected).
-91 %
Submenu
This menu is not displayed for PROFIBUS
PA or for excitation frequencies 50 Hz or
70 Hz.
Data 60 Hz
Channel view only
Adjustment value for Channel can be moni-
tored for the excitation frequency setting
(displayed when an older primary 60 Hz has
been selected).
ENTER -123 µs
Zero view only
Adjustment value for Zero can be monitored
for the excitation frequency setting (dis-
played when an older primary 60 Hz has
been selected).
0 %
Span → F view only
Adjustment value for Span Forward can be
monitored for the excitation frequency set-
ting (displayed when an older primary 60 Hz
has been selected).
91 %
Span ← R view only
Adjustment value for Span Reverse can be
monitored for the excitation frequency set-
ting (displayed when an older primary 60 Hz
has been selected).
-91 %
Submenu
This menu is not displayed for excitation fre-
quencies 50 Hz or 60 Hz.
Data 70 Hz
Channel view only
Adjustment value for Channel can be moni-
tored for the excitation frequency setting
(displayed when a new flowmeter primary
was selected).
ENTER -123 µs
