ABB SE41F - Page 30

30 S4 D184B122U02
Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Mains frequency view only
Display of the mains frequency for the flow-
meter primary. Selections only available for
„Older Model“.
50 Hz
Type of Primary view only
Display of the type of flowmeter primary
connected.
SE2_, SE4_
Meter Size view only
Display of the flowmeter primary size.
Selections only available for „Older Model“.
1 mm 1/25 in
Reference Voltage view only
Display of the reference voltage value only
for „Older Model“, see type tag on the flow-
meter primary. Not displayed for Model
10D1422.
70 mV
Cal-fact view only
Display of the max. possible flow range . Au-
tomatically selected from the flowmeter size
selection.50 m3/h
Qmax numeric entry
Flow range end value for forward and
reverse flow directions. Flow range end val-
ue range can be set between 0.5 and
10 m/s.50 m3/h
Damping 1 τ
numeric entry Response time, after 1τ the displayed
value has reached 63% of its actual value
(after 5τ).
1 sec
Low flow cut off
numeric entry
0–10 % of Qmax
Applies to the values displayed and all
outputs. The switch point has a built in
hysteresis off 0.1 % .
1.0 %
Submenu
Information!
Only if the meter pipe is completely filled will
a correct measurement be made. The func-
tion "Detector empty pipe" can be used to
continuously monitor this condition. If the
fluid level drops below the electrode level,
then all outputs can be automatically set to
zero. Thereby erroneous pulses and indica-
tions can be avoided when the meter pipe is
empty. When the meter pipe is full, the error
message „empty pipe“ is turned off and the
systems returns to normal operation.
Detector e. pipe
Detector e. pipe
Off
On
Turn the empty pipe detector on or off. Not
available for meter sizes:
1 mm 1/25 in
1.5 mm 1/17 in
2 mm 1/12 in
3 mm 1/10 in
4 mm 5/32 in
6 mm 1/4 in
8 mm 5/16 in
Information!
Empty pipe detection is not available for
flowmeter primaries with preamplifiers.
ENTER Off
