32 S4 D184B122U02
Submenu/
Parameter
Submenu/
Parameter
Submenu/
Parameter
Selections
Value Range
Comments
Display 1st line
Q [Percent]; Q [Unit];
Iout [mA];
Q [m/s]; Q Bargraph
Totalizer;
Totalizer
→ F;
Totalizer ← R; Totaliz-
er Diff.; HART TAG;
Detector e. pipe;
Blank line
Selections for the 1st display line
Q [Percent]
Display 1st line
For instruments with PROFIBUS PA there
are in other display values available in addi-
tion to the following: flowrate in percent, en-
gineering units, m/s, Bargraph, totalizer,
totalizer → F, Totalizer ← R, Totalizer Diff.,
Detector empty pipe:
PA Addr+State The Bus-Address and the
status of the cyclical communication (STOP,
CLEAR or OPERATE) are displayed.
PA Addr + State
Display 1st line
TB VolFlow Value The value for the
Volume_Flow (Transducer block Index 17) is
displayed.
TB VolFlow Status The Status of the
Volume_Flow (Transducer block Index 17) is
displayed.
TB VolFlow Value
Display 1st line
TB VolFlow Status
Display 1st line
TB Total → F Value The Value of the total-
izer → F (Transducer block Index 102) is dis-
played.
TB Total → Status The Status of the total-
izer → F (Transducer block Index 102) is dis-
played.
TB Total ← R Value The Value of the total-
izer ← R (Transducer block Index 104) is
displayed.
TB Total ← R Status The Status of the to-
talizer ← R (Transducer block Index 104) is
displayed.
TB Total Diff Value The Value of the differ-
ence totalizer (Transducer block Index 106)
is displayed.
TB Total Diff Status The Status of the dif-
ference totalizer (Transducer block Index
106) is displayed.
TBT→FValue
Display 1st line
TBT→FStatus
Display 1st line
FB AI OUT The OUT-Value of the AI-Block
is displayed. The after the decimal point
numbers result from the Decimal-Point in
the OUT_SCALE-Structure. The displayed
Unit is the UNIT_INDEX from the
OUT_SCALE-Structure.
FB AI OUT
Display 1st line
FB AI Status Here the Actual-Mode of the
particular block and the status of the Out-
put-Variables (OUT. Status) is displayed. Af-
ter the Status, if required, the Substatus is
displayed as a number. Example BAD 3 in-
dicates that the Status is BAD, Substatus is
3 = device failure.
For descriptions of the number codes see
the Data Link documentation.
FB AI Status
