SwirlMaster FSS430, FSS450 VortexMaster FSV430, FSV450 | CI/FSS/FSV430/450-EN Rev. D 13
Digital output
Terminals DIGITAL OUTPUT 1+ / DIGITAL OUTPUT 4-
U
M
45 V
Zone 1: Ex d ia IIC T6 Gb/Ga
T
amb
= -40 ... 75 °C
Zone 21 Ex tb IIIC T85 °C Db
T
amb
= -40 ... 75 °C
XP-IS (US) CL I/DIV I/GP BCD, DIP CL II, III/DIV I/ GP EFG
XP-IS (Kanada) CL I/DIV I/GP BCD, DIP CL II, III/ DIV I/GP EFG
CL I, ZONE 1, AEx/Ex d ia IIC T6 -40 °C < Ta < +75 °C
TYPE 4X Tamb = 75 °C „Dual seal device“
Analog input
Terminals ANALOG INPUT + / ANALOG INPUT -
U
M
45 V
Zone 1: Ex d ia IIC T6 Gb/Ga
T
amb
= -40 ... 75 °C
Zone 21 Ex tb IIIC T85 °C Db
T
amb
= -40 ... 75 °C
XP-IS (US) CL I/DIV I/GP BCD, DIP CL II, III/DIV I/ GP EFG
XP-IS (Kanada) CL I/DIV I/GP BCD, DIP CL II, III/ DIV I/GP EFG
CL I, ZONE 1, AEx/Ex d ia IIC T6 -40 °C < Ta < +75 °C
TYPE 4X Tamb = 75 °C „Dual seal device“
Special Requirements
The devices must be installed in a protected environment in
accordance with the specific conditions on the test certificate.
Pollution degree 3 (see IEC 60664-1) must not be exceeded
for the macro environment of the device.
The devices are in accordance with the IP rating IP66 / IP67. If
the device is installed correctly, this requirement is met by the
housing as standard.
When connected to the power supply / not connected to the
power supply, the electrical circuits must not exceed
overvoltage category III / II.
2.5 Temperature resistance for the connecting cables
The temperature at the cable entries of the device is
dependent on the measuring medium temperature T
medium
and the ambient temperature T
amb.
.
For electrical connection of the device, cables suitable for
temperatures up to 110 °C (230 °F) can be used without
restriction.
Use in category 2 / 3G
For cables suitable only for temperatures up to 80 °C (176 °F),
the connection of both circuits must be checked in the event
of a fault. Otherwise, the restricted temperature ranges listed
in the following table shall apply.
Use in category 2D
For cables suitable only for temperatures up to 80 °C (176 °F),
the restricted temperature ranges listed in the following table
shall apply.
T
amb
1)
T
medium
maximum
Maximum cable temperature
40 ... 82 °C
(-40 ... 180 °F)2)
180 °C (356 °F) 110 °C (230 °F)
-40 ... 40 °C
(-40 ... 104 °F)2)
272 °C (522 °F) 80 °C (176 °F)
-40 ... 40 °C
(-40 ... 104 °F)
400 °C (752 °F)
-40 ... 67 °C
(-40 ... 153 °F)
180 °C (356 °F)
1) The permissible limits for the ambient temperature are dependent on approval
and design (default: -20 °C [-4 °F])
2) Category 2D (dust-ignition proof), maximum 60 °C (140 °F)
