SwirlMaster FSS430, FSS450 VortexMaster FSV430, FSV450 | CI/FSS/FSV430/450-EN Rev. D 9
Change from two to one column
2.3.3 Limit value tables
Operating temperature ranges:
— The ambient temperature range T
amb
of the devices is -40 ... 85 °C.
— The measuring medium temperature range T
medium
is -200 ... 400 °C.
Devices without LCD indicator
Power supply, current / HART output, analog input
Temperature class T
amb
max. T
medium
max. U
max
I
max
P
i
max
T4 ≤ 85 °C 90 °C 30 V 100 mA 0.75 W
≤ 82 °C 180 °C
≤ 81 °C 280 °C
≤ 79 °C 400 °C
T4 ≤ 70 °C 90 °C 30 V 160 mA 1.0 W
≤ 67 °C 180 °C
≤ 66 °C 280 °C
≤ 64 °C 400 °C
T5 ≤ 56 °C 90 °C 30 V 100 mA 1.4 W
≤ 53 °C 180 °C
≤ 52 °C 280 °C
≤ 50 °C 400 °C
T6 ≤ 44 °C 90 °C 30 V 50 mA 0.4 W
≤ 41 °C 180 °C
≤ 40 °C 280 °C
≤ 38 °C 400 °C
Digital output
Temperature class T
amb
max. T
medium
max. U
max
I
max
P
i
max
T4 ≤ 85 °C 90 °C 30 V 30 mA 1.0 W
≤ 82 °C 180 °C
≤ 81 °C 280 °C
≤ 79 °C 400 °C
T4 ≤ 70 °C 90 °C 30 V 30 mA 1.0 W
≤ 67 °C 180 °C
≤ 66 °C 280 °C
≤ 64 °C 400 °C
T5 ≤ 56 °C 90 °C 30 V 30 mA 1.0 W
≤ 53 °C 180 °C
≤ 52 °C 280 °C
≤ 50 °C 400 °C
T6 ≤ 44 °C 90 °C 30 V 30 mA 1.0 W
≤ 41 °C 180 °C
≤ 40 °C 280 °C
≤ 38 °C 400 °C
