ABB SYNCHROTACT 5 - Page 139

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 139
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
Rev.
Ind.
Page (P)
Section (S)
Descriptions
(or revision status)
Date
Dept./Exec.
C S 2.2.2 Addition: Working range voltage matcher 05.09.20
ATPE/WZ
C S 3.1 New type code 05.09.20
ATPE/WZ
C S 3.2 Modification: Note: RS232 replaced by Ethernet 05.09.20
ATPE/WZ
C S 3.3 Modification of the communication interfaces
RS232 to Ethernet, previous option Ethernet
cancelled; New blocking input
05.09.20
ATPE/WZ
C S 3.4 Modification: previous option Ethernet cancelled
and new input range fro auxiliary voltage.
05.09.20
ATPE/WZ
C S 4.2.1 Modification and addition of paragraph "Angle
tuning
 Offset"
05.09.20
ATPE/WZ
C S 4.2.8 Addition: New configuration possibilities for digital
outputs
05.09.20
ATPE/WZ
C S 5.2.2 New section for engineering: compensation of
phase-angle difference
05.09.20
ATPE/WZ
C S 5.8 Addition: Relay type of SYN 5500 05.09.20
ATPE/WZ
C S 7.1.1 Addition: Table of commands 05.09.20
ATPE/WZ
C S 7.1.3 Modification: RS232 replaced by Ethernet 05.09.20
ATPE/WZ
C S 7.2.3 Modification: SynView with optional password 05.09.20
ATPE/WZ
C S 8.2.8 Modification under "Caution": compensation of
phase shifts not by
 Offset
05.09.20
ATPE/WZ
C S 9.2.3 Modificationen event list: 060, 061, 073, 127
New in the event list: 077, 078, 079
05.09.20
ATPE/WZ
C S 10.1 Modification: range of the auxiliary voltage
New: digital inputs: minimum voltage for logic 1
05.09.20
ATPE/WZ
C S 10.2 Modification / Addition: relay data 05.09.20
ATPE/WZ
C S 10.4 Modification: accuracy data 05.09.20
ATPE/WZ
C S 10.5 Modification: changed values after repeating of the
type test for climatic and EMC tests
05.09.20
ATPE/WZ
C S 11 Modification: New interfaces and blocking input 05.09.20
ATPE/WZ
